The value of A2 is equivalent to 10100010 in binary. As mentioned above, the value entered in the bytes section is a hexadecimal number. ✱ NOTE : In t he second custom parameter, the value of A2 in the bytes section instructs the IOX-AUXM to put auxiliaries 2, 6, and 8 into the Low-High state. To do so, the user must apply the following custom parameters: In this example, the user wants to configure auxiliaries 2, 6, and 8 to have a Low-High state, and the remaining auxiliaries to have the High-Low state.
Example of manually configuring the auxiliary A value of 0 configures the corresponding auxiliary into Ground-High or Float-High configurations, while a value of 1 configures the auxiliary to detect a Ground-Float circuit - explained further in the example below.
the number of digital auxiliaries that a GO device monitors). The two digits for bytes in the custom parameter above is an 8-bit long hexadecimal number that corresponds to an AUX number ranging from 1 to 8 (i.e. The information entered into the bytes section of the parameter specifies the auxiliaries that are configured to a manual state.
Input Impedance of each AUX : 30.3 kΩ or 80.6 kΩ (depending on input voltage range)ĭriving Circuit Resistance must be less than 100 ΩĪutomatically identifies GND-Float, Float-Driven and GND-Driven driving circuits with capacitive loading of Īdditionally, to configure an auxiliary to operate with the three circuit types listed above, the following custom parameter must be applied.
